| Item |
D |
d |
B |
Z |
V |
E-max |
Description |
Dimensions |
X |
NOTE |
| TA140.07530 |
140 |
30 |
4÷7,5 |
4 |
4 |
32 |
|
|
A+A |
|
| TA140.07535 |
140 |
35 |
4÷7,5 |
4 |
4 |
32 |
|
|
A+A |
|
| TA140.07630 |
140 |
30 |
8 |
2 |
|
32 |
|
|
B |
|
| TA140.07635 |
140 |
35 |
8 |
2 |
|
32 |
|
|
B |
|
| TA140.15030 |
140 |
30 |
4÷15 |
4+2 |
4 |
32 |
|
|
A+B+A |
|
| TA140.15035 |
140 |
35 |
4÷15 |
4+2 |
4 |
32 |
|
|
A+B+A |
|
| TA180.07530 |
180 |
30 |
4÷7,5 |
8 |
4 |
37 |
|
|
A+A |
|
| TA180.07535 |
180 |
35 |
4÷7,5 |
8 |
4 |
37 |
|
|
A+A |
|
| TA180.07630 |
180 |
30 |
8 |
2 |
|
37 |
|
|
B |
|
| TA180.07635 |
180 |
35 |
8 |
2 |
|
37 |
|
|
B |
|
| TA180.15030 |
180 |
30 |
4÷15 |
8 |
4 |
37 |
|
|
A+B+A |
|
| TA180.15035 |
180 |
35 |
4÷15 |
8 |
4 |
37 |
|
|
A+B+A |
|
| Z055.020.N |
|
|
|
|
|
|
Knife |
18x18x1,95 |
|
Spare parts working for TA140.075 / TA180.075 |
| Z051.700.R |
|
|
|
|
|
|
Knife screw |
M4x3,2 |
|
Spare parts working for TA140.075 / TA180.075 |
| Z060.701.R |
|
|
|
|
|
|
Threaded ring |
12×1,7 |
|
Spare parts working for TA140.075 / TA180.075 |
| Z055.006.N |
|
|
|
|
|
|
Spur |
14x14x1,2 |
|
Spare parts working for TA140.075 / TA180.075 |
| Z051.700.R |
|
|
|
|
|
|
Spur screw |
M4x3,2 |
|
Spare parts working for TA140.075 / TA180.075 |
| Z060.700.R |
|
|
|
|
|
|
Threaded ring |
10×1,65 |
|
Spare parts working for TA140.075 / TA180.075 |
| Z055.000.N |
|
|
|
|
|
|
Knife |
7,6x12x1,5 |
|
Spare parts working for TA140.076 / TA180.076 |
| Z056.700.N |
|
|
|
|
|
|
Wedge |
7 |
|
Spare parts working for TA140.076 / TA180.076 |
| Z051.800.R |
|
|
|
|
|
|
Wedge screw |
M5x18 |
|
Spare parts working for TA140.076 / TA180.076 |
